What We Do
Do-yourself-solar technologies are helping folks make and assemble their own solar electric - photovoltaic (PV) modules and solar thermal (heat and hot-water) panels. We schedule and carry out hands-on seminars and workshops in Maine as well as many other places that folks are interested in "working towards self-sufficiency".
A hand-made 65w PV module on display powering a radio at WERU fair in Maine, June, 2007.
--------------------------
We offer free consultation for those desiring a more self-reliant lifestyle.
We are a not-for-profit, Solar educational Corp. doing hands-on PV assembly seminars for more than 30 years.
We also design and facilitate do-yourself solar greenhouse construction; Solar cookers and food dryers; and thermal projects for heat and hot-water.
---------------------------------
2013 -
Cell ph charger assembly, step-by-step:
1- Diamond wheel and guide for scoring cell for 1/4 size, .5V and 800ma, for 6V cell ph charger, 2013.
----------------------------------
2 - Scoring PV cell for proper size, .5V, 800ma, for 6V cell ph charger, 2013.
-----------------------------------
3 - 12 cut PV cells ready for series connection soldering for cell ph charger, 2013.
---------------------------------
4
4 - 12 cut PV cells in frame for position check, cell ph charger assembly, 2013.
--------------------------------
5 - Soldering ribbon on front (neg) side of cut PV cell, for string series connection, 2013. Continued on right column >
--------------------------------------.JPG)
Solar PV workshop participants check string of cells for voltage and amps before encapsulation in 65W PV module. Harrington, Me, Grange - Feb 17, 2008.
Some of the PV workshop participants at the soldering table, May '09 Pottstown, PA
------------------------------------------------
MESEA and Concerns of Spreading Do-Yourself-Solar Information...
After hearing concerns from those involved with MESEA, and talking to others, we have tried to give a short explanation of why MESEA is not concerned with the do-yourself-solar PV assembly workshop information being used by those who have experienced it.
The reason we give the workshops, is to further our efforts, by spreading the low-tech, do-yourself methods and help those with low skill levels, create a self-reliant lifestyle for themselves and their families. This work, around the world, has helped those with less education and opportunities, establish PV “cottage industries” that will benefit their communities and neighbors.
We function as a not-for-profit corporation. Again, our desire is to spread the technology, to help create the beneficial effects between communities, local and world-wide, of self-reliance and sharing. Those who would “profit” by using these simple, low-tech methods are invited to do so, as long as the credit is given to those who have developed the methods used.
The same philosophy is attached to other do-yourself-solar projects included in the Maine Solar Primer and on more and more web-sites. Please feel free to help us spread this technology, so those less fortunate may feel the benefits and excitement of creating something that can give them a step towards self-reliant lifestyle and world peace. A world that is not profiting on the exploitation of each other, for non-renewable resources, will be that much closer to reaching true peace.
----------------------------------
Solar PV assembly workshop participant, April, 2011, in Brooklyn, NY, solders cells for a string to be included in 65W PV module for roof garden use at the Commons. Photo by Mishon, thanks.
----------------------------
Dadsolar / MESEA, learning facilitator, John Burke, with PV workshop participants, test a 65W PV module, at the Brooklyn Commons, roof garden. The PV will power a garden fountain and possible irrigation system. This photo by Mishon, April, 2011, thanks.
-------------------------------
Solar PV workshop soldering table, ready for participants to solder the strings for a 65W PV module. Photo by Otto, Brooklyn, NY, April, 2011.
--------------------------------
A familiar scene, PV assembly workshop participants, solder cells for PV strings, to be used in the 65W PV module. Alley Pond Environmental Center, Douglaston, Queens, NYC, May 14, 2011... This workshop is a NYSES / MESEA, co-production.
---------------------------
An enthusiastic group, around the encapsulated 65W PV module. At the APEC PV workshop, May 14, 2011. This workshop is a NYSES / MESEA, coop workshop.
---------------------------------------------
John Burke, of DADSolar, and the MESEA workshop facilitator, prepares soldering board for group at NESEA-NJ PV assembly workshop, So. Plainfield, NJ, March, 2011. This workshop was hosted by New York Solar Energy Society, (NYSES), an ASES Chapter.
------------------------------------
Dr. Richard Komp, presenting low-tech "Solar Oven, EVA lamination" power-point, at the ASES Conference, Raleigh, NC, May 18, 2011.
The enthusiastic crowd was interested in this latest innovation for the Third-World PV "Cottage Industry", now in 12 countries. DADS and MESEA are promoting the efforts of Dr. Komp and Skyheat Associates, to establish sustainable renewable energy business development for communities in the developing world.
-----------------------------------
Participants solder solar cells for 65W PV module with Kenya American Society group in New Jersey, Feb. 2012. The group is interested in starting a PV "cottage industry" business in a poor community in Kenya!
------------------------------
Kenya American Society participants, after finishing 65W PV module framing, Feb. 2012.
-----------------------------------
DADSOLAR is buying the Solar Home of Dr. Richard Komp, Jonesport, Maine, Get involved!
Jonesport, Maine, Solar Home, east side, Oct. '09-----------------------------
Dr. Komp on South side deck with PV array, Oct. '09---------------------------------
University of Maine, Orono, Professors, workshop participants, help John Burke prepare the soldered strings for encapsulation. Jonesport, Maine, Oct. 2011, DADS / MESEA solar PV assembly workshop. ---------------------------------------
Southern view of Indian River and Gulf of Maine from living room, looking out over south deck. Solar Home, Jonesport, Maine, Oct '09, low-tide.-------------------------- We are looking for folks who would like to be part of ...DADS, Inc.-Downeast Alternative Design Solar A Solar Educational Communityat the Jonesport, Maine, Solar Home!
--------------------------------------------
*SOLAR INTERNSHIP PROGRAM
Spring/Summer/Fall 2012 !
Our focus is re-kindled toward a Spring / Summer / Fall structure re-build at the Jonesport, Solar Home, as well as the SEADS Solar Seminar Center, in Columbia, Maine...
This spring, summer and fall, we hope to attract a group of interns with skills and enthusiasm for the necessary jobs ahead !
Please share this with folks who may be interested in learning about the PV assembly, Solar thermal collectors, Greenhouse construction and every-day maintainance at the Washington Co., Maine, facilities. Call the phone #s listed here for reservations and further information on this years intern program.
Thank you & Go Solar !
---------------------------------
-----------------------------------
Call Us Today!
Please contact us today. We are always eager to help folks determine how solar and other renewable energy technologies may help them and help solve some of the problems of our planet and it's inhabitants.
Phone: (207)-546-1639
(207)-497-2204
(207)-356-0225
(516)-669-2442
(207)-483-2764
E-mail - dadsolar@yahoo.com
Web links -
www.seadsoftruth.webs.com(SEADS)
www.mainesolar.org (MESEA)
A soldered string of PV cells, ready forplacement (with 3 others), on 65w PV module.
Our low-tech approach allows anyone to gain skills in this important field and become part of the solution.
----------------------------.JPG)
Preparing for final wiring and framing of 65W module - Feb 17, 2008 - Harrington, Me, Oceola Grange.
------------------------------------
Handmade PV rack for 49, 65W PV modules, assembled at St. George PV workshop Fall 2008.
------------------------------------------------
An updated photo of the 'homemade PV array' installed above the factory modules, at St. George, ME, soon to be connected to the 'grid' , Summer '12
--------------------------------------------
Charles a solar enthusiast from Rhode Island, soldering a string of cells for PV encapsulation. During the Solar PV Spring Intensive, Jonesport. ME - Apr. 2011.
-------------------------------------------------------------
John and Charles at PV Spring Intensive Assembly workshop, April, 2011, set glass onto 3 strings of 12 solar cells. A 36 cell, 65W PV module. Four modules, assembled during the PV Spring Intensive, will be installed at Jonesport, ME, solar seminar center.
-------------------------------------------
Cell Ph charger assembly, continued ...
2013 ...
6 - four cut cells ready for string soldering cell ph charger assembly, 2013.
-----------------------------
7 - Four cell string ready for series connection to three other strings for cell Ph charger, 2013.
-------------------------------
8 - three strings of four PV cells, soldered in series connection (adds Volts), for 6V cell Ph charger, ready for frame, 2013.
--------------------------------------
9 - Finished 12 PV cell (6V), cell Ph charger in 'dollar store' picture frame, ready for Ph adapter wire connect (your Ph ?), 2013.
-------------------------------------
Solar PV powered clock at Manhattan Comprehensive HS, NYC, 2011. This PV module uses ambiant light, in indoor atrium, to supply power for 3V time piece.
---------------------------------
Any weight may be used in low-tech laminating process, to help the air-bubbles out the edge of the glass, during encapsulation of the PV module. The table is level, photo by Mishon, Apr, 2011, Bklyn, NY.
-------------------------------
PV workshop participant, solders finishing touches on PV string, before testing. The positive ribbons must be added onto the back of the last cell. Photo by Otto, thanks, Brooklyn, NY, April, 2011.
---------------------------------
Participant at NESEA-NJ / NYSES / MESEA cooperative PV assembly workshop, March, 2011, prepares to solder PV cells for the first time. The 4 strings of 9 cells, will be used in the 65W PV module completed that day, at the So. Plainfield, NJ site. (Due to unforseen events, some folks had to leave before the final framing, and were able to attend our Brooklyn, NY workshop a few weeks later, in April, 2011.)
-----------------------------------
Close-up of cut PV cells, being soldered in series, for impromptu battery charger assembly workshop at ASES Conference, Raleigh, NC. May 18, 2011.
------------------------------
Final wiring of battery charger, at ASES Conference hallway, PV workshop, May 18, 2011, Raleigh, NC. The AA, C or D size, solar "trickle charge", -battery charger, can charge regular Alkaline, as well as, "re-chargble" batteries. The case, made for MESEA, by the Penobscot Indian Nation, Old Town, Maine.
------------------------------
Interested ASES Conference attendees, marvel at the solar PV battery charger, impromptu workshop, in the hall of Raleigh Convention Center, May 18, 2011.
--------------------------------
Student group, March, 2012, at the Manhattan Comprehensive HS class with MESEA facilitator, John Burke, during PV assembly workshop. The liquid silicon encapsulation method, developed by Marco Antonio, of Suni Solar, Nicaragua, is used to seal the 4 strings of 9 solar cells on this 65W PV module. This PV workshop is our fourth annual solar project, with Man. Comp. HS, CDI and Solar1, of NYC.
--------------------------------
DADS, Inc. learning facilitator, John Burke, applies first application of liquid silicon encapsulant, at MESEA PV assembly workshop, Jonesport, Maine, Solar Home, Oct. 2011.
-----------------------------------
MESEA solar PV assembly workshop participants, stand ready for encapsulation process on the 4 strings of 9 PV cells after soldering and testing. This workshop, on Earth Day weekend, April, 2012, was hosted by DADS and SEADS of Truth.
-----------------------------------------
South side of Solar Home, Jonesport, Maine. Greenhouse and PV Hybrid panel, from deck, Oct. '09
--------------------------------------
DADS, Inc., is looking for a few "Good Folks" interested in being part of a new Intentional Solar Community & Education Cntr., established in Jonesport, Maine.
Extensive re-build and additional space to be constructed at 5 acre, ocean view, Solar Home site.
--------------------------------
Solar Educational Community Development Project, includes part-time family participation !
---------------------------------
Time-Share Opportunities!
What an opportunity for individuals and families, to experience the self-reliant lifestyle. This time-share development, along with the full-time participantion, will allow folks to experience a solar educational community based atmosphere on the rugged Maine coast! Please call phone #s listed below, thanks.
